3003 000 9731 - STIHL 25"/63cm Chainsaw Bar
Length: 63cm / 25"
Pitch: .404" / 10.26mm
Drive Links: 77
Gauge: .063" / 1.6 mm
Kick Back Protection: None
Suits Model: 066, 660, MS660 (with .404" Sprocket)
The STIHL ROLLOMATIC® E Super guide bar is a solid-machined bar made of high-grade steel with the groove milled out and a replaceable sprocket nose assembly riveted in place. The sprocket is incorporated in the replaceable sprocket nose assembly of the bar and carries the saw chain from the top to the bottom of the bar. This not only reduces wear, but also enables the bar nose to be made considerably narrower. This type of construction is an advantage where extensive use is made of the bar nose (i.e. limbing and boring). All STIHL ROLLOMATIC® bars designed with a narrow nose help reduce kickback tendencies. And the sprocket nose assembly can be replaced several times before the whole bar is due for replacement, increasing the service life of the bar.
WARNING: This is a yellow labeled bar. This product has increased risk of kickback injury and is for use only by persons with extraordinary cutting needs and experience and specialized training for dealing with kickback. Do not use this bar unless you have experience and specialised trainsing to prevent kickback. Bars with reduced kickback potential are available. Please contact us, or read you Stihl manual, if you require further information about safety precuations.
WARNING: The occurrence called "kickback" can cause serious or fatal injury. Always read the instruction manual carefully before using your saw. Stihl uses a green and yellow color-coding system to help you select a powerhead, bar and chain combination that complies with the kickback requirements of AS 2726.1-2004 (Australian Standards - Chansaw Safety Requirements). Contact us for information about operating procedures to reduce the risk of injury.
were applicable, we recommend the use of the "green" reduced kickback bars and "green" low kickback chains on all Stihl chain saws.
